James Watt
Watt212 Stainless Steel Decorative Metal Panels for Wall Cladding & Insert
Watt-212 is a stainless steel decorative metal panels which is made of stainless steel wire, it has a open area of almost 0%, so almost no light can pass through, it can be used for
It is particularly suitable for exterior and interior wall cladding & wire mesh inserts, bar counter infill panels, etc.
Specifications
- Open area: 5%
- Material: 304 stainless steel wire
- Wire diameter: 2 mm (0.079 in.)
- Overall thickness: 5mm (0.197 in.)
- Weight: 14.44 kg/m2 (2.96 lb/ft2)
Technical Specification
Specifications of Watt-212: Stainless Steel Decorative Mesh Panels
| Product Name | Watt-212 |
| Material | SS 304/316 |
| Wire Size (d1), mm (in) | 1.4 (.055) |
| Wire Size (d2), mm (in) | 2 (.079) |
| O1, mm (in) | 12 (.472) |
| O2, mm (in) | 8.5 (.335) |
| Overall thickness, mm (in) | 4.7 (.185) |
| Open Area | 3 % |
| Max Width | 1.2m (4 ft) |
| Max Length | 2.8m (9 ft) |
| Approx. Weight, kg/m2 (lb/ft2) | 14.4 (2.96) |
Product Details
