Faraday10039 Decorative Wire Mesh Infill Panels for Balustrade
Faraday-10039 is a decorative wire mesh infill panels which can be used for Balustrade. It is a component used in various architectural and construction applications. It typically consists of a grid or network of intersecting metal wires, forming a mesh pattern. These panels are commonly used as infill material in architectural features such as railings, fences, balustrades, and partitions.
Technical Specification
Specifications of Architectural Wire Mesh Infill Panels
| Product Name | Faraday-10039 |
| Material | 304/316 Stainless Steel |
| Wire Size (d1) | 10 mm (.039 in) |
| Wire Size (d2) | 3 mm (.118 in) |
| Opening (O1) | 19 mm (.0748 in) |
| Opening (O2) | 6.7 mm (.264 in) |
| Opening (O3) | 4.5 mm (.177 in) |
| Overall thickness | 3 mm (.118 in) |
| Open Area | 42.6 % |
| Max Width | 1.2m (4 ft) |
| Max Length | 2.8m (9 ft) |
| Approx. Weight | 6 kg/m2 (1.23 lb/ft2) |
Product Details
